Appliance Stability Safety Test Equipment

Appliance Stability Tester

Product Origin : China
Item NO. : ZLT-WD2
Shipping Port : Guangzhou
MOQ : 1
Lead Time : In 25 Working Days
Payment : T/T, D/P

Contact Now

Product Details

Appliance Stability Tester

Product details: Model ZLT-WD2

Table Diameter : 800mm Manual Control

ZLT-WD2D : Electric Model

To determine the stability of electric appliances which are used on a table or on the floor, in accordance with IEC60065 clause 19.1, IEC60335-1 clause 20.1, IEC60601-1 clause 24.1, IEC 60950 clause 4.1.1. The device consists of a surface and a threaded spindle with handwheel for adjusting the incline of the table board from the horizontal up to 30° against the horizontal.

Standard Outfit:

1 table board, with supporting frame,
1 base plate with hinges for the supporting frame and for the spindle bearing,
1 threaded spindle with handwheel for adjusting the incline of the table board from the horizontal up to 30°against the horizontal,

1 inclination angle measuring instrument, to mount at the table board, for checking the angle of inclination of the table board,

Model	ZLT-WD1	ZLT-WD2	ZLT-WD2D	ZLT-WD3	ZLT-WD3D
Table Diameter	600mm	800mm	800mm	1000mm	1000mm
Rotation Mode	Manual control	Manual Control	Electric Model	Manual Control	Electric Model
Rotation Speed			1 rpm		1 rpm
Inclination Angle	0-30±1°	0-30±1°	0-30±1°	0-30±1°	0-30±1°
Permissible Load	Less than 50 kgs	less than 80 kgs	less than 80 kgs	less than 120 kgs	less than 120 kgs

CE Certificate for Inclined Plane Device
